Odours are typically released into the atmosphere as diffuse emissions from area and volume sources, whose detailed quantification in terms of odour emission rate is often hardly achievable by direct source sampling. Indirect methods, involving the use of micrometeorological methods in order to correlate downwind concentrations to the emission rates, are already mentioned in literature, but rarely found in real applications for the quantification of odour emissions.

   The instrumentation needed for the development of micrometeorological methods has nowadays become accessible in terms of prices and reliability, thus making the implementation of such methods to industrial applications more and more interesting.



   In a non-hazardous waste landfill an integrated odour monitoring system comprised with 2 IOMS, 2 H2S continuous analyser and two automatic air samplers has been operating since 2018: automatic air samplers are activated when two consecutive measurements of 20 ppb at 5 min intervals are measured by H2S continuous analyser or when overall odour emission measured by IOMS exceeded 500 ouE/m3 for more than 5 min.

   Problems with odour emissions were noticed in May-August 2019 with almost a daily automatic samplers’ activation, often correlated with complaints of population; moreover, monitoring campaigns of biogas from the landfill surface showed significant increase of surface emissions for certain zones, implying that surface and fugitive emissions form landfill biogas (LFG) collecting system could have been responsible for such odour emissions. The LFG wellfield system of is comprised of a network of 301 vertical wells in the landfill, coupled with conveyance piping for the transport of LFG to energy recovery and 3 blowerflare facilities.

   Odour impact is generally low around Waste Water Treatment Plants (WWTP) when conventional Odour Control Unit (OCU) such as chemical scrubbers or biofilters are implemented. However, for some specific WWTP processes such as sludge thermal drying releasing odorous Volatile Organic Compounds (VOC) in particular aldehydes and ketones, these conventional OCU are not effective enough to avoid odour nuisances in the environment.

   To fix this issue, we have proposed a simple and relevant two stages treatment line to treat odorous VOCs from WWTP. The first step of the treatment line consists of an enhanced water scrubber (absorption) and the second one, an Activated Carbon (AC) filter (adsorption). The enhanced water scrubber, patented by Suez and named AzurairTM Cool, uses a chiller to cool the inlet scrubber water in order to increase VOCs removal in scrubber and dehumidifie air before the second stage of AC filtration.
